技術參數:
|
規格型號 Model & norm |
ZD-3000V |
ZD-3300V |
|
最大折疊 Maxinmum size |
4000×3000 |
3300 |
|
最大折疊層次(次/層) Most folding levels |
5/32 |
5/32 |
|
工作效率(m/min) Flding speed |
50 |
50 |
|
氣源壓力 Operating compressed air pressure |
0.7 |
0.7 |
|
壓縮空氣耗量(㎡/min) Compressed air consumption |
1.2 |
1.2 |
|
額定輸入功率 Power supply |
1.87 |
1.87 |
|
耗電量(kw/h) Electric consumption |
0.8 |
0.8 |
|
壓縮空氣排量(㎡/min) Required air compressor capacity |
0.3 |
0.3 |
|
進氣管徑 Inlet lowest pressure |
φ12 |
φ12 |
|
電源線徑(㎜2) Externally connected power supply cabel size |
4 |
4 |
|
工作電壓(V) Washing voltage |
380 |
380 |
|
整機重量 Overall weight |
1430 |
1630 |
|
外形尺寸 Exterior dimension |
4160×2930×1750 |
4460×2930×1750 |
